Place of Origin : Guangdong, China
Brand Name : Joyful Partner
Model Number : C825068
Packaging Details : Shockproof Carton Box
Supply Ability : 500000 Carton/Cartons per Month
MOQ : 2 pieces
Price : Negotiable
Color Temperature(CCT) : 2700k-6500k
Lamp Luminous Efficiency(lm/w) : 100
Color Rendering Index(Ra) : 80
Support Dimmer : Yes
Lighting solutions service : Project Installation
Lifespan (hours) : 50000
Working Time (hours) : 50000
Product Weight(kg) : 1.13
Warranty(Year) : 2-Year
Input Voltage(V) : DC 24v,12v
Working Temperature(℃) : -20 - 40
Working Lifetime(Hour) : 50000
Lamp Body Material : Stainless steel
IP Rating : IP67, IP67 Waterproof
Application : Step,stair,Deck,Boat,Humid environment
Light Source : LED
Item Type : LED Underground Light
Shape : Round
Lamp size : Dia.108mm*H.90mm
Glass : 8mm Tempered step glass
OEM&ODM : Available
Power : 6 Wattage
Certificate : CE,RoHS,EMC
Lens effciency : ≥85%
Transport Package : Shockproof Carton Box
Port : Guangzhou/Shenzhen
Item No. | Light source | Lens beam angle(°) | Consumption(watt) | Input Voltage(V) | Ik rate |
| 1*6W COB LED | 15°/25°/38°/60° | | | |
C825069(AS) | 1*6W RGBW4 in1 | 25°/25°/40°/10*65°/20*65° | 8.1W | DC12V/DC24V | 8 |
C825109(AS) | 1*6W RGBW 4in1 | 25°/25°/40°/10*65°/20*65° | 10.2W | DC12/24V | 8 |
Material specifications | | |
Housing | 12#Die-casting outdoor powder painting aluminum.T=60-80μm Adhesion of ISO Glass 1/ASTM Glass 4B | |
Front cover | 304# or 316#Stainless Steel | |
Lens | Optical lens,effciency≥85% | |
Glass | Tempered glass.T=8mm | |
Gasket | Molding shaped silicone double seal | |
Operating temperature | (-20℃~40℃) | |
Power cable | H05RN-F2*0.75mm²L=0.5m(low voltage) H05RN-F3*0.75mm²L=0.5m(for single color/high voltage) H05RN-F5*0.5mm²L=0.5m(for RGBW) | |
Mounting sleeve | ABS | |
Optional accessory | Honeycomb |
15°/24°/36°/60° |
![]() |
6W Outdoor LED Underground Light IP67 12V DC Low Voltage Inground Light Images |
